Dudek Universal 1.1
Dudek Universal 1.1
Regular price
$3,700.00 USD
Regular price
Sale price
$3,700.00 USD
Unit price
per
Couldn't load pickup availability
Have Questions?
As you start researching you'll find yourself having more and more questions. Our full-time team is available 7 days a week to answer any question you might have. Please don't hesitate to reach out!
Call or Text - (801) 599-1684
Email - Info@BackcountryPPG.com
TECHNICAL DATA
| Size | 23 | 25.5 | 28 | 31 | 34 |
| Certification | EN/LTF B | EN/LTF B | EN/LTF B | EN/LTF B | – |
| Approval – ULM identification | yes | yes | yes | yes | yes |
| Cell number | 50 | 50 | 50 | 50 | 50 |
| Surface area flat [m2] | 23.00 | 25.50 | 28.00 | 31.00 | 34.00 |
| Surface area projected [m2] | 19.83 | 21.98 | 24.14 | 26.72 | 29.31 |
| Wingspan flat [m] | 10.83 | 11.40 | 11.95 | 12.57 | 13.17 |
| Wingspan projected [m] | 8.71 | 9.17 | 9.61 | 10.11 | 10.59 |
| Aspect ratio flat | 5,10 | ||||
| Aspect ratio projected | 3,83 | ||||
| Sink [m/s] | min = 1,1 | ||||
| Speed* [km/h] | min = 23; trim = 37-52; max = 57 (+/- 3 km/h)* | ||||
| Longest chord [mm] | 2612 | 2751 | 2882 | 3033 | 3176 |
| Shortest chord [mm] | 601 | 633 | 663 | 698 | 731 |
| Lines+risers length [m] | 6.82 | 7.18 | 7.53 | 7.92 | 8.29 |
| Total lines length [m] | 344.01 | 362.82 | 380.74 | 401.20 | 420.70 |
| Weight range PPG/PPGG*** [kg] | 60-95 | 70-115 | 90-140 | 110-170 | 135-215 |
| Weight range PG** [kg] | 60-75 | 70-95 | 90-115 | 110-140 | (135-170) |
| Weight of the wing [kg] | 5.6 | 5.95 | 6.4 | 6.85 | 7.35 |
| Distance betwen risers [cm] | 42 | 46 | 46 | 46 | 45-60 |
| Lines | Technora 90 & 140 & 190 & 280 & 340 & 420 | ||||
| Cloth | Porcher Classic 38 g/m2 Dominico 34 g/m2, Porcher Hard 40 g/m2, SR Scrim, SR Laminate 180 g/m2 |
||||
| Risers | Pasamon – Bydgoszcz, Polska | ||||
