Dudek Hadron 3
Dudek Hadron 3
Regular price
$4,100.00 USD
Regular price
Sale price
$4,100.00 USD
Unit price
per
Couldn't load pickup availability
TECHNICAL DATA
| Hadron 3 – size |
16 | 18 | 20 | 22 | 24 |
| Approval – ULM identification | yes | yes | yes | yes | yes |
| Number of cells | 62 | ||||
| Surface area (flat) [m2] | 16.00 | 18.00 | 20.00 | 22.00 | 24.00 |
| Surface area (projected) [m2] | 13.52 | 15.21 | 16.89 | 18.58 | 20.27 |
| Span (flat) [m] | 9.80 | 10.39 | 10.95 | 11.49 | 12.00 |
| Span (projected) [m] | 7.80 | 8.28 | 8.73 | 9.15 | 9.56 |
| Aspect ratio (flat) | 6.00 | ||||
| Aspect ratio (projected) | 4.51 | ||||
| Sink [m/s] | min = 1.2 (+/- 0.2 m/s) | ||||
| Speed* [km/h] | min = 29 ; trim = 45-58 ; max = 71 (+/- 3 km/h)* | ||||
| Distance pilot to wing [m] | 5.78 | 6.13 | 6.46 | 6.78 | 7.08 |
| Total lines lenght [m] | 223.10 | 237.26 | 250.66 | 263.41 | 275.58 |
| Total take-off weight** [kg] | 80-100** | 90-110** | 100-120** | 110-135** | 120-150** |
| Max take-off weight – for experienced*** [kg] | 115*** | 130*** | 140*** | 155*** | 170*** |
| Distance between risers [cm] | 45 | 45 | 45 | 45 | 45 |
| Weight of the wing [kg] | 4.30 | 4.66 | 4.92 | 5.28 | 5.64 |
| Lines | A-8000U: 050; 090; 130; 190 / Technora: 90; 140; 190; 280 / Dyneema: 350 | ||||
| Fabric | Porcher Classic 38 g/m2 / Dominico tex 34 g/m2 / Porcher Hard 40 g/m2 / SR Scrim / SR Laminate 180g/m2 | ||||
